Sweepers

KGA 770 - AP-System

STIHL KGA 770
STIHL KGA 770
KGA 770 Skin Only
KGA 770 Skin Only
KGA 770
KGA 770
KGA 770 Skin Only
KGA 770 Skin Only
$1,399.00
All prices include 10% GST.
Select item
  • Battery sweeping machine for large areas both indoors and outdoors
  • Individual tool without battery and without charger
  • Dust-free work thanks to the integrated air filter
    • Available to buy from STIHL Approved Dealers
    Buy this product at one of our many local stores. Find a store and contact the dealer for information about the availability.

    Technical details

    Rated voltage36 V
    Cordless power systemAP
    Recommended batteryAP 200
    Weight16.9 kg
    Container capacity40 l

    Features

    The pictures shown are sample photos. The actual appearance of the equipment features and their specific attachment to the product may differ from the pictorial representations, but will have the same functionality.

    FOR A LONG SERVICE LIFE. Thanks to their special arrangement, the bristles also reliably pick up targeted debris lying flat on the ground, such as wet leaves. The bristles of your sweeping machine are made of wear-resistant polyamide plastic; this material is characterised by high elasticity and robustness, giving the bristles a very long service life.
    VERY ROBUST BRISTLES
    WITH A LARGE CAPACITY. The large waste container holds a lot of waste. The handle makes it easy and quick to connect the waste container to the sweeping machine. This prevents the contents from falling out.
    WASTE CONTAINER
    PROTECTS YOUR BACK. You can adapt the ergonomically shaped push bar to your size and in this way move the power tool in a way that is gentle on your back and low effort, even when working for longer periods. The push bar can be easily removed for transport and storage.
    ERGONOMIC PUSH BAR
    FOR EASIER HANDLING. Direct drive for the sweeping brushes makes it easier to push your sweeping machine. Direct power transmission from the gears to the brushes also ensures significantly better efficiency compared to belt-driven power tools. If you move the power tool backwards, the circular brushes rotate inwards, thereby preventing dirt from being flung out.
    LONG TRANSMISSION
    HOLDS BACK DUST. When working with your sweeping machine, the circumferential sealing strip reliably holds back swirled-up dust. Combined with air filters, this means very little dust is released into the environment as you sweep.
    CIRCUMFERENTIAL SEALING STRIP
    REDUCE DUST DEVELOPMENT AND ARE WASHABLE. In combination with intelligent air guidance, the two foam air filters hold back dust. This means that significantly less dust escapes to the outside while sweeping fine material. Both filter elements can be easily removed and washed out for cleaning.
    AIR FILTERS FOR SWEEPING MACHINES
    FOR BETTER SWEEPING PERFORMANCE. With the bristle hold-down clamp, your sweeper can clean thoroughly and reliably even in hard-to-reach places such as edges or directly alongside kerbs. Simply press the bristle hold-down clamp downwards when sweeping edges.
    BRISTLE HOLD-DOWN CLAMP

    Top of the range STIHL battery sweeper

    The STIHL KGA 770 battery sweeping machine is ideal for professionals and ambitious private users who want to clean large areas indoors and outdoors. Thanks to the STIHL MultiClean Plus sweeping system and the sweep width of 77 cm, coarse dirt on surfaces in factory halls and on interlocking or paving stones can be removed efficiently with this battery-powered sweeper. The circular brushes and the additional power sweep are powered by a battery from the STIHL AP System. This means that the KGA 770 sweeping machine always operates quietly at an optimum speed and is easy to guide. The rotating power sweeps also work at a suitable speed when the sweeper is stationary. Debris is picked up reliably and does not escape into the environment thanks to the sealing strip aroand the power sweep, which works in conjunction with an air filter.

    The transmission of the power sweeps and circular brushes and the two-level adjustable ergonomic push handle enable you to push the STIHL KGA 770 comfortably. The circular brushes also turn inwards when reversing so that no dirt is ejected. Additional protective caps on the brush gear protect it from dirt and water.

    You can adjust the STIHL KGA 770 battery sweeper for any surface using the 8-level central height adjustment function, which can also be used to adjust the bristles. The bristle hold-down devices ensure cleanliness even along edges and in corners. The circular brushes are very durable, with robust bristles made from wear-free nylon.  The push handle can be removed easily for compact, upright storage of the sweeper.

    Our overview of STIHL battery life and charging times shows how much lawn area you can work on with one battery charge of your STIHL KGA 770 battery sweeper and how long the installed battery takes to charge.

    • Area covered with recommended AP 200 / S battery: Up to 168m²
    • Area covered with AP 300 S battery: Up to 260m²
    • Area covered with AP 500 S battery: Up to 312m²
    STIHL KGA 770
